零件號碼 |
頻率 |
峰值增益 |
平均的 |
回波損耗 |
0433AT62A0020 |
423-443 |
-4.0(XZ-總計) |
-4.0(XZ-總計) |
9.5 |
0433AT62A0020E-AEC |
423-443 |
-4.0(XZ-總計) |
-4.0(XZ-總計) |
9.5 |
0490AT62A0040 |
470-510 |
-3.0(XZ-總計) |
-6.0(XZ-總計) |
4.4 |
0783AT43A0008 |
779-787 |
-2.0(XZ-總計) |
-5.0(XZ-總計) |
9.5 |
0868AT43A0020 |
858-878 |
1.0(XZ-總計) |
-4.0(XZ-總計) |
9.5 |
0868AT43A0020E-AEC |
858-878 |
1.0(XZ-總計) |
-4.0(XZ-總計) |
9.5 |
0900AD47A2450 |
858-928 |
-1.0(XZ-總計) |
-4.5(XZ-總計) |
3 |
0900AD54B2450 |
858-928 |
1.1 |
-2.4 |
6.5 |
0900AT43A0070 |
858-928 |
-0.5(XZ-總計) |
-2.5(XZ-總計) |
4 |
0915AT43A0026 |
902-928 |
-1.0(XZ-總計) |
-4.0(XZ-總計) |
8.5 |
1227AT45A0042 |
1206-1249 |
1.0(XZ-V) |
-2.0(XZ-V) |
9.5 |
1575AT43A0040 |
1561-1602 |
-1.5(XZ-V) |
-2.5(XZ-V) |
9.5 |
1575AT44A0010 |
1570-1580 |
0.5(XZ-V) |
-2.0(XZ-V) |
9.5 |
1575AT54A0010 |
1570-1605 |
1.3(YZ-總計) |
-0.7(YZ-總計) |
9.5 |
1582AT54A0045 |
1560-1605 |
1.5 dBi(典型值)。 |
-0.5 dBi(典型值)。 |
9.5 |
1600AT45A0040 |
1580-1620 |
0.0(XZ-總計) |
-1.0(XZ-總計) |
9.5 |
1905AT45A0050 |
1880-1930 |
0.5(XZ-總計) |
-1.1(XZ-總計) |
9.5 |
2000AT18A0075 |
1965-2040 |
0.3(XZ-V) |
-3.0(XZ-V) |
9.5 |
2440AT62A0085 |
2400-2485 |
3.5 |
|
6 |
2440AT62B0085 |
2440-2485 |
+2.1典型值。(XZ-總計 )RHCP |
+1.3(XZ-總計) |
9.5 |
2450AD14A5500 |
2400-2480 |
1.0(YZ-總計) |
-3.5(XZ-總計) |
6 |
2450AD14A5500T-AEC |
2400-2480 |
1.0(YZ-總計) |
-3.5(XZ-總計) |
6 |
2450AD18A7250 |
2400-2480 |
+3.0 (YZ-cut) |
+0.4 (YZ切割) |
6.5分鐘。 |
2450AD18A7250E-AEC |
2400-2480 |
+3.0 (YZ-cut) |
+'0.4 (YZ切割) |
6.5分鐘。 |
2450AD46A5400 |
2400-2500 |
1.0(XZ-V) |
-2.5(XZ-V) |
8.5 |
4900-5900 |
-1.5(YZ-V) |
-2.5(YZ-V) |
||
2450AD47A1590 |
2400-2500 |
1.0(YZ-總計) |
-1.5(XZ-總計) |
8 |
2450AD47A1590E-AEC |
2400-2500 |
1.0(YZ-總計) |
-1.5(XZ-總計) |
8 |
2450AT07A0100 |
2400-2500 |
1.0(XZ-總計) |
-1.5(XZ-總計) |
6.5 |
2450AT07A0100T-AEC |
2400-2500 |
1.0(XZ-總計) |
-1.5(XZ-總計) |
6.5 |
2450AT14A0100 |
2400-2480 |
-0.5(XZ-總計) |
-2.0(XZ-總計) |
6 |
2450AT18A100 |
2400-2500 |
0.5(XZ-V) |
-0.5(XZ-V) |
9.5 |
2450AT18A100E-AEC |
2400-2500 |
0.5(XZ-V) |
-0.5(XZ-V) |
9.5 |
2450AT18B100 |
2400-2500 |
0.5(XZ-V) |
-0.5(XZ-V) |
9.5 |
2450AT18D0100 |
2400-2500 |
1.5(XZ-V) |
-1.0(XZ-V) |
10 |
2450AT18D0100E-AEC |
2400-2500 |
1.5(XZ-V) |
-1.0(XZ-V) |
10 |
2450AT18E0100 |
2400-2500 |
1.0(YZ-總計) |
-3.0(YZ-總計) |
4.4 |
2450AT42A100 |
2400-2500 |
0.0(XZ-V) |
-1.0(XZ-V) |
9.5 |
2450AT42B100 |
2400-2500 |
0.0(XZ-V) |
-1.5(XZ-V) |
9.5 |
2450AT42D0100 |
2400-2500 |
0.5(XZ-總計) |
-2.0(XZ-總計) |
6 |
2450AT42E0100 |
2400-2480 |
-2.0(YZ-V) |
-4.6(YZ-總計) |
4.5 |
2450AT42E0100E-AEC |
2400-2480 |
-2.0(YZ-V) |
-4.6(YZ-總計) |
4.5 |
2450AT42E010B |
2400-2480 |
-1.0 (YZ-V) |
-4.6(YZ-總計) |
(調諧版本1) 2.7分鐘。 |
2450AT42E010BE-AEC |
2400-2480 |
-1.0 (YZ-V) |
|
(調諧版本1) 2.7分鐘。 |
2450AT43A100 |
2400-2500 |
2.0(XZ-V) |
0.5(XZ-V) |
9.5 |
2450AT43B100 |
2400-2500 |
1.3(XZ-V) |
-0.5(XZ-V) |
9.5 |
2450AT43F0100 |
2400-2500 |
2.1(XZ-總計) |
1.0(XZ-總計) |
9.5 |
2450AT45A100 |
2400-2500 |
3.0(XZ-V) |
1.0(XZ-V) |
9.5 |
2450AT45A100E-AEC |
2400-2500 |
3.0(XZ-V) |
1.0(XZ-V) |
9.5 |
2500AT43A0100 |
2450-2550 |
0.6(YZ-總計) |
-2.1(YZ-總計) |
6 |
2500AT44M0400 |
2300-2700 |
2.0(2.38千兆赫) |
0.0(2.38千兆赫) |
9.5 |
2600AT44A0600 |
2300-2900 |
2 |
0 |
9.5 |
2650AT43A0100 |
2600-2700 |
0.5(YZ-總計) |
-1.7(XZ-總計) |
6 |
3100AT51A7200 |
3100-10300 |
1.5 |
-3.5 |
9.5 |
3600AT43A0400 |
3.4-3.8 |
1.6 |
-1.8 |
9.5 |
4000AT44A1800 |
3100-4900 |
2.7 |
-3.5 |
7.4 |
5400AT18A1000 |
4900-5900 |
2.0(XZ-V) |
-2.5(XZ-V) |
8.5 |
5500AT07A0900 |
5150-5875 |
0.0(YZ-總計) |
1.0(YZ-總計) |
6 |
5500AT18A0725 |
5150-5875 |
2.0(XZ-V) |
-2.5(XZ-V) |
9.5 |
7000AT18A1600 |
6200-8240 |
2 |
-0.5 |
9.5 |
7000AT18A1600E-AEC |
6200-8240 |
2 |
-0.5 |
9.5 |
